The Ultion lock has been tested to the needs of the British Standard TS007 3 star standard, without having to be bolstered with an expensive high security handle. When Ultion is locked it is the actual centre cam that gets independently secured, not secured to the internal plug – this means that even when the key is left on the inside of the lock, Ultion is still secure.

The Ultimate standard that other 3-star anti-snap locks want but don’t get. This is the rigours of the TS007 3-star but with added aggression, and tested by an MLA locksmith. The tester is allowed more access around the lock, more tools, freedom to break the material surrounding the lock and the ability to pause the clock to consider a different tack – Ultion will also be tested to this standard

Underneath the key sit 6 pins. Each of these pins have specific jobs, there are 2 steel anti drill pins, 3 brass mushroom anti-pick pins, and one anti-bump. But then, above the key Ultion is housing a further 5 pins – creating an astonishing 294,000 key combinations.

Debris dropping into the lock jams locks. Ultion keeps itself clean in three ways.
First the key way is not a gaping hole ready to welcome anything from pocket fluff to small insects. In fact the shape is designed to wipe the key clean at the point of entry.
Also, there are no magnets on the key. This means that damaging metal scrapings from coins and other keys are not carried into the lock when stuck magnetically on the key. Finally, because Ultion has 11 pins (creating 294,000 key combinations) there is no need to create extra deep key dimples for debris to hide and sneak into the lock.

For all the wizardry inside Ultion, all the customer ever does with it is put the key in and turn! Ultion takes the fiddle and dark knight key missing keyhole drama away by giving your customer a guiding recess for the key to quickly find it's location.

ULTION 2.jpg



20 HARDENED STEEL ANTI-DRILL PINS


 Anti drill pins have featured in existing high end locks for a while. Ultion however has 6, in both sides of the body (because it is non-handed!). So the burglar meets the first two in the sacrificial section of the cylinder. But if he decides to snap the lock first then go for the drill he’ll find his drill bit fighting against 4 more anti-drill pins. In the plug itself is a further 8 (each side of course) and two anti drill plates (yes... each side!)

THE MOST SNAP RESISTANT CYLINDER LOCK


 Normal, handed anti-snap locks feature a single sacrificial section and focus on strength to make snapping harder. Except the strength is never enough to withstand the force leveraged from a burglar's mole grips. On each end of an Ultion cylinder there are two sacrificial elements, each designed to snap with relative ease, but more importantly in exactly the right place. When snapped the central cam is directly and independently locked – not to an attack-able internal plug.
